6000mAh 128 Elements Wifi Ultrasound USG Wireless USG Probe 12.6cm

Name: 6000mAh 128 Elements Wifi Ultrasound USG Wireless USG Probe 12.6cm
Brand: Golead Medical Group Co.,Ltd
SKU: H35L
Availability: InStock

Brand Name:	Golead
Model Number:	H35L
MOQ:	1 Unit
Delivery Time:	2 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO13485

Product Name:

6000 MAh Internal Battery Smart Phone Wireless Ultrasound Tranducer

Element:

128

Scanning Mode:

Electronic Linear Array

Frequency:

4/8.3/12MHz

Language:

English/Chinese

Cineloop:

100 Frames

Display Mode:

B/C/M/PW/PD

Image Storage Format:

DICOM, BMP, PNG, JPEG

Battery:

6000 MAh, Maximum 4.5-hour Continuous Use

N/W:

330g

G/W:

530g

Warranty:

1 Year

Body Mark:

Yes

Size:

179*75*34mm

Packaging Details:

carton box

Supply Ability:

1,000 units per month

Highlight:

6000mAh wireless usg probe

wireless usg probe 12.6cm

128 elements wifi ultrasound usg 12.6cm

Product Description

6000mAh 128 Elements Wifi Ultrasound USG Wireless USG Probe 12.6cm

Product Overview

The H35L Wireless Ultrasound Probe is a highly advanced medical imaging device that utilizes cutting-edge technology to provide exceptional imaging capabilities. This portable ultrasound system offers a user-friendly interface for easy operation and flexibility in various clinical settings.

Key Features

6000mAh internal battery for extended operation
Choice of convex and linear probes for various diagnostic procedures
Specialized application packages with automatic measurements
Real-time low-latency image processing up to 30 frames per second
Spatial composite imaging and speckle reduction technology
Phase inversion tissue harmonic imaging for clear imaging
Ultra-portable design for versatile clinical settings

Technical Specifications

Parameter	Specification
Scanning mode	Electronic Linear Array with 128 elements
Display mode	B/C/M/PW/PD
Central frequency	8.3MHz
Depth	12.6cm
Zoom	Four times
Channel	32
Dynamic Range	180dB
Sampling Rate	50MHz
Gray	256
FPS	From 8 to 30
Packing Dimension	25519060mm
Video Storage	MPEG-4

Applications

Vascular, small parts, MSK, nerve

Package Contents

Wireless Ultrasound Probe - H35L
Internal Battery
Charging Cable
User Manual
Wireless Charger

Clinical Image
