Place of Origin:
China
Brand Name:
Golead
Certification:
ISO13485
Model Number:
MU15
Contact Us
Laptop Portable Feline Canine Equine Veterinary Ultrasound Machine
Application
For bovine, ovine, equine, canine, feline and other domestic animals. It is applicable for the inspection and diagnosis of middle and small size animal’s liver, gallbladder, spleen, kidney, bladder, uterus, and other organs.
Main Features
15 in color liquid crystal display Laptop Veterinary Ultrasound Machine
Windows 7 operation system ( Chinese and English)
One-click full screen
Metal+nickel plating process probe interface
Built-in lithium battery with 18650 international standard, work last for mor than 4hs
Equipped with Ultra ISO, system recovering USB flash disk
Tow storage mode, hard disk 128G , U disk storage
Probes auto freeze function
Puncture line guide
Display mode-B,B+B,4B,B+M,M,PW
Power Doppler Mode, measure Blood flow volume, velocity of blood flow, pulse index
Basic Parameters
Main gain:2-100
8 TGC: adjustable
Dynamic range: 0-390dB
Focus:4
Pseudo color: 8
Body marks: 20kinds (canine*4, feline*2, equine*6, bovine*6, ovine*2)
Scanning range:5%-100%
Image reversal: up/down,left/right
Edge enhancement: 0-7
Ultrasonic power :0-15
Image smoothing:0-7
Image reversal: up/down,left/right,black/white
Measurement: General measurement, GYN & OB measurement package
Probe depth: 3.5MHz:90-250mm/6.0MHz:70-145mm/7.5MHz:40-90mm/ 6.5MHz:50-125mm
Parameters
| Scanning mode | electronic convex array, electronic linear array |
| Probe element | 128 |
| Monitor | 15'’ LCD |
| Display mode | B/C/PWD/M |
| Warranty | 2 years |
| Depth | 50 to 250Mm |
| Weight | 7.5g |
| Power consumption | <1.8W |
| Image to screen ratio | >85% |
| Frame rate | 11-13FPS |
| Gray | 256 |
| DBody marks | 20 kinds |
Applications
Bovine, Equine, Ovine, Swine, etc
Standard configuration
Veterinary Ultrasound Machine with Mirco-convex Probe and linear probe
Optional
Covex probe
Rectal linear probe
